This parts catalog covers International Harvester Farmall M, MV, MD, and MDV tractor models manufactured between 1939 and 1952. These tractors were renowned workhorses in American agriculture, celebrated for their durability and versatility. The M and MD models featured a standard two-wheel drive configuration, while the MV and MDV variants offered a tricycle front end for enhanced maneuverability in row-crop cultivation. Available with either gasoline (M, MV) or diesel (MD, MDV) engines, these tractors provided robust performance with engine displacements of 248 cubic inches and approximately 33-37 belt horsepower. Their design prioritized operator visibility and control, making them a staple on farms for over a decade.
This comprehensive English-language parts catalog, identified as TC-28H, provides detailed component-level information essential for identifying and procuring replacement parts. It includes exploded drawings for visual part identification, official International Harvester part numbers, and specifications on part quantities per vehicle. The catalog clearly indicates model and year applications, detailing when specific part revisions were implemented. Coverage extends to engine components, transmission parts, chassis, steering, electrical systems, hydraulics, bodywork, and wheels. While not a diagnostic manual, this catalog is an invaluable resource for owners, mechanics, and technicians seeking to maintain and restore these classic International Harvester tractors.
1939-1952 Farmall M, MV, MD & MDV Tractor Parts Catalog TC-28H. This Parts Catalog offers a complete listing on every part on the tractor it contains exploded drawings for correct assembly and identification, part numbers, part names, descriptions and dimensions necessary for proper identification of parts, part quantities used per vehicle, model application, and the year a part was used.
* INSTANT DOWNLOAD NO WAITING
* PDF FORMAT
---------------------------------------------------------------------------------------------
Farmall M Tractor Specs
Model introduced 1939
Model discontinued 1952
Model status Discontinued
No. produced 282,911 (includes Farmall M-MD-MV-MDV)
Preceded by McCormick-Deering Farmall F-30
Superseded by McCormick Farmall Super M
Engine Specification
Engine make International
Engine model C-248
Fuel type gasoline
Power hp 36 belt, 33 drawbar
Governed rpm 1450
Displacement cu in /(litre) 248 ci
No. of Cylinders 4
Bore in (mm) 3.875 in
Stroke in (mm) 5.25 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA
Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 5
Reverse 1
Drive 2-WD
General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 6.00-16 4-ply
Rear 11-38 6-ply
Tractor Dimensions
Length (inches/metres) 132 in
Width (inches/meters) 85 in
Height (inches/meters) 76 in
Weight (nominal) lb/kg 4415 lb
Turning circle (nominal) inches/meters 17 ft
Wheelbase 89 in
Other info
Factories Tractor Works, Chicago, Illinois
Plow rating 3-14"
Nebraska Tests No. 328
Approximate Cost new in (year) $1112 (1941), $2346 (1952)
---------------------------------------------------------------------------------------------
Farmall MV Tractor Specs
Model introduced 1942
Model discontinued 1952
Model status Discontinued
Preceded by McCormick-Deering Farmall F-30 Cane Tractor
Superseded by McCormick Farmall Super MV
Engine Specification
Engine make International
Engine model C-248
Fuel type gasoline
Power hp 36 belt, 33 drawbar
Governed rpm 1450
Displacement cu in /(litre) 248 ci
No. of Cylinders 4
Bore in (mm) 3.875 in
Stroke in (mm) 5.25 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA
Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 5
Reverse 1
Drive 2-WD
General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 7.50-20 4-ply
Rear 13.6-38 6-ply
Tractor Dimensions
Length (inches/metres) 147 in
Width (inches/meters) 86 in
Height (inches/meters) 90 in
Weight (nominal) lb/kg 5505 lb
Turning circle (nominal) inches/meters 25 ft
Wheelbase 92 in
Other info
Factories Tractor Works, Chicago, Illinois
Plow rating 3-14"
Nebraska Tests No. 328
---------------------------------------------------------------------------------------------
Farmall MD Tractor Specs
Model introduced 1941
Model discontinued 1952
Model status Discontinued
Preceded by New model
Superseded by McCormick Farmall Super MD
Engine Specification
Engine make International
Engine model D-248
Fuel type diesel
Power hp 37 belt, 33 drawbar
Governed rpm 1450
Displacement cu in /(litre) 248 ci
No. of Cylinders 4
Bore in (mm) 3.875 in
Stroke in (mm) 5.25 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA
Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 5
Reverse 1
Drive 2-WD
General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 6.00-16 4-ply
Rear 12-38 6-ply
Tractor Dimensions
Length (inches/metres) 133 in
Width (inches/meters) 85 in
Height (inches/meters) 76 in
Weight (nominal) lb/kg 4745 lb
Turning circle (nominal) inches/meters 17 ft
Wheelbase 90 in
Other info
Factories Tractor Works, Chicago, Illinois
Plow rating 3-14"
Nebraska Tests No. 368
Approximate Cost new in (year) $3335 (1952)
---------------------------------------------------------------------------------------------
Farmall MDV Tractor Specs
Model history
Model introduced 1945
Model discontinued 1952
Model status Discontinued
Preceded by New Model
Superseded by McCormick Farmall Super MDV
Engine Specification
Engine make International
Engine model D-248
Fuel type diesel
Power hp 37 belt, 33 drawbar
Governed rpm 1450
Displacement cu in /(litre) 248 ci
No. of Cylinders 4
Bore in (mm) 3.875 in
Stroke in (mm) 5.25 in
Cooling system water
Naturally aspirated, Turbo or Supercharged NA
Transmission Details
Transmission type sliding gear
Gearbox make International
Forward 5
Reverse 1
Drive 2-WD
General Data
Linkage Category drawbar
Tyre Sizes (std/options)
Front 6.00-20 4-ply
Rear 10.00-36 6-ply
Tractor Dimensions
Length (inches/metres) 148 in
Width (inches/meters) 86 in
Height (inches/meters) 90 in
Weight (nominal) lb/kg 5835 lb
Turning circle (nominal) inches/meters 25 ft
Wheelbase 93 in
Other info
Factories Tractor Works, Chicago, Illinois
Plow rating 3-14"
Nebraska Tests No. 368
