The Linde Order Picker Truck Type 015, covering models V11-04 and V12-04, represents a robust and efficient solution for warehouse order picking operations. Engineered for high-density warehousing, this electric-powered truck is designed to optimize throughput and energy efficiency. Its advanced features include sophisticated guidance systems, such as mechanical rail and inductive wire guidance, ensuring precise travel and automated operation. The operator's console and control desk are designed with ergonomics and ease of use in mind, providing clear operational status displays and intuitive controls for enhanced productivity and operator comfort.
This operating instructions manual provides comprehensive guidance for the safe and effective use of the Linde Order Picker Truck Type 015. It covers essential areas including vehicle description, safety systems, operator controls, battery management, braking, fork movements, guidance systems, load engagement, and emergency procedures. The manual details operational procedures from commissioning and pre-start checks to safe operation, load engagement, and various travel modes. It also includes information on interpreting error messages and troubleshooting common operational issues, supported by high-quality images and circuit diagrams. This resource is intended to assist owners, operators, and technicians in maintaining and operating the vehicle to manufacturer standards.
Original Illustrated Factory Operating Instructions (User Manual) for Linde Order Picker Truck Type 015.
Original factory manuals for Linde Forklift Trucks, contains high quality images, circuit diagrams and instructions to help you to operate and repair your truck
Covered models:
V11-04
V12-04
Format: PDF, 129 Pages
Language: English, Deutsch, Français, Italiano, Español
Contents:
Foreword
Description
Standard operating conditions, Truck
identification, Intended use
Safety
Safety remarks relating to work with
operating media
Description of truck
Safety equipment
Dimensions
Technical data
View truck
Operators console, Operating devices
Control desk operating status display
Operation
Transport and loading,
Commissioning
Mounting the battery,
Battery change
Battery commissioning,
Performance testing
Battery check
Battery discharge indicators and service hour meters
Swichting on the control
Checklist before starting work
Safety advice for operation
Safety advice for engaging loads
Initial driving practice outside the rack aisle
Braking system, Emergency OFF
Travelling in the rack aisle
Control of the fork movements
Travelling within the mechanical rail guidance,
Changing the rack aisles
Inductive wire guidance
Entering the rack aisle,
Automatic travel
Leaving the rack aisle,
Leaving the induction track
Engaging loads, Diagram of loads
Engaging loads
Emergency lowering
Emergency operation
Towing, Error messages
Emergency rope device
Emergency rope device,
Operating instructions
Maintenance, checking and storage of the emergency rope device
Fuses, Optional attachments
Special equipment, load side operating console
Maintenance
Lubricants, Decommissioning
Lubrication schedule
Maintenance schedule
Maintenance every 6 months
Maintenance yearly
Alphabetical index
